Price:
$ 35.17

Free Shipping

For just $ 35.17 , buy DANMINI MJPT019 RFID Card Access Control Electric Magnetic Lock Door Access Control System Kit from the wholesale webshop online.

Specifications

Certificate CE, FCC, RoHS
Color White
Home Safety Type Smart Card Access Control
Retail Packaging Paper Box
Gross Weight 1.658kg
Volume Weight 0.634kg
Length 24.500cm
Width 16.500cm
Height 7.000cm
Weight 1.480kg
With Retail Packaging Yes

Product Description

DANMINI MJPT019 RFID Card Access Control Electric Magnetic Lock Door Access Control System Kit
  • This RFID proximity access controller using proximity system is one of the modern access control systems

  • It is powerful and can open the door using proximity cards, passwords, or the hybrid

  • The access controller can provide users with more convenience by connecting to terminals, including the button for opening the door, doorbell, and electric magnetic lock that is normally open or closed

  • The access control system offers a method for controlling access safely and automatically, qualifying it as an ideal equipment for businesses, offices, factories, and communities

  • With CE, FCC and RoHS certifications

Specification:

  • Host technical parameters:

  • Working voltage: DC8V-15V (standard 12V)

  • Electric current: Don't drive lock ≤70mA

  • Unlock the electric current: ≤1000mA

  • Working temperature: -10°C ~ 70°C

  • Working humidity: 0~100%

  • Frequency: 125KHz (EM CARD)13.56MHz (M1 CARD)

  • Initial programming password: 123456

  • Magnetic locks technical parameters:

  • Working voltage: DC 12V input

  • Working current: 320mA

  • Sustain tension: 180KG (straight line pull)

  • Lock body material: High strength aluminum alloy and anode hardening treatment

  • Installation method: With the electric lock (small)

  • Suitable for: 90 degrees of any box door open

  • Switch technical parameters:

  • Standard structure: Fireproof material mixed resin

  • Electrical properties: The maximum durability 3A@36V DC

  • Contact  output: NO/COM contact

  • Durability test: One hundred thousand times aging test qualified

  • Suitable type: Apply the hollow frame and embedded type electric appliance box use

  • Working temperature: -10°C ~ 55°C(14°F ~ 131°F)

  • Working humidity: 0~95% (Relative humidity)

  • Panel processing: Fire prevention materials off surface treatment

  • Size: 86 x 86 x 20mm

  • Weight: 0.07kg

Package included:

  • 1 x Entrance Guard Host
  • 1 x Door Wwitch
  • 1 x Door Dedicated Power Supply
  • 1 x Magnetic Lock
  • 10 x ID Cards (125 KHZ)
  • 1 Pack of Screws and Accessories
